Multiplication in FPGA Design!!



 Multiplication is basically a shift add operation.  There are, however, many variations on how to do it.  Some are more suitable for FPGA use than others.   This page is a brief tutorial on multiplication hardware.  The hyperlinked items in this list are currently in the text.  The remaining items will be added in a future release of this page.

Scaling Accumulator Multipliers

	Parallel by serial algorithm
	Iterative shift add routine
	N clock cycles to complete
	Very compact design
	Serial input can be MSB or LSB first depending on direction of shift in accumulator
	Parallel output

A scaling accumulator multiplier performs multiplication using an iterative shift-add routine.  One input is presented in bit parallel form while the other is in bit serial form.  Each bit in the serial input multiplies the parallel input by either 0 or 1.  The parallel input is held constant while each bit of the serial input is presented.  Note that the one bit multiplication either passes the parallel input unchanged or substitutes zero.  The result from each bit is added to an accumulated sum.  That sum is shifted one bit before the result of the next bit multiplication is added to it.

1      1011001 0     0000000 1    1011001  1  +1011001      10010000101

Serial by Parallel Booth Multipliers

	Bit serial adds eliminate need for carry chain
	Well suited for FPGAs without fast carry logic
	Serial input LSB first
	Serial output
	Routing is all nearest neighbor except serial input which is broadcast
	Latency is one bit time

The simple serial by parallel booth multiplier is particularly well suited for bit serial processors implemented in FPGAs without carry chains because all of its routing is to nearest neighbors with the exception of the input.   The serial input must be sign extended to a length equal to the sum of the lengths of the serial input and parallel input to avoid overflow, which means this multiplier takes more clocks to complete than the scaling accumulator version.  This is the structure used in the venerable TTL serial by parallel multiplier.

Ripple Carry Array Multipliers

	Row ripple form
	Unrolled shift-add algorithm
	Delay is proportional to N

A ripple carry array multiplier (also called row ripple form) is an unrolled embodiment of the classic shift-add multiplication algorithm.  The illustration shows the adder structure used to combine all the bit products in a 4x4 multiplier.  The bit products are the logical and of the bits from each input.  They are shown in the form x,y in the drawing.  The maximum delay is the path from either LSB input to the MSB of the product, and is the same (ignoring routing delays) regardless of the path taken.  The delay is approximately 2*n.

This basic structure is simple to implement in FPGAs, but does not make efficient use of the logic in many FPGAs, and is therefore larger and slower than other implementations.

Row Adder Tree Multipliers

	Optimized Row Ripple Form
	Fundamentally same gate count as row ripple form
	Row Adders arranged in tree to reduce delay
	Routing more difficult, but workable in most FPGAs
	Delay proportional to log2(N)

Row Adder tree multipliers rearrange the adders of the row ripple multiplier to equalize the number of adders the results from each partial product must pass through.   The result uses the same number of adders, but the worst case path is through log2(n) adders instead of through n adders.  In strictly combinatorial multipliers, this reduces the delay.  For pipelined multipliers, the clock latency is reduced.   The tree structure of the routing means some of the individual wires are longer than the row ripple form.  As a result a pipelined row ripple multiplier can have a higher throughput in an FPGA (shorter clock cycle) even though the latency is increased.



Carry Save Array Multipliers

	Column ripple form
	Fundamentally same delay and gate count as row ripple form
	Gate level speed ups available for ASICs
	Ripple adder can be replaced with faster carry tree adder
	Regular routing pattern

Look-Up Table (LUT) Multipliers

	Complete times table of all possible input combinations
	One address bit for each bit in each input
	Table size grows exponentially
	Very limited use
	Fast - result is just a memory access away

Look-Up Table multipliers are simply a block of memory containing a complete multiplication table of all possible input combinations.  The large table sizes needed for even modest input widths make these impractical for FPGAs.

The following table is the contents for a 6 input LUT for a 3 bit by 3 bit multiplication table.

	000	001	010	011	100	101	110	111
000	000000	000000	000000	000000	000000	000000	000000	000000
001	000000	000001	000010	000011	000100	000101	000110	000111
010	000000	000010	000100	000110	001000	001010	001100	001110
011	000000	000011	000110	001001	001100	001111	010010	010101
100	000000	000100	001000	001100	010000	010100	011000	011100
101	000000	000101	001010	001111	010100	011001	011110	100011
110	000000	000110	001100	010010	011000	011110	100100	101010
111	000000	000111	001110	010101	011100	100011	101010	110001

Partial Product LUT Multipliers

	Works like long hand multiplication
	LUT used to obtain products of digits

Partial products combined with adder tree

Partial Products LUT multipliers use partial product techniques similar to those used in longhand multiplication (like you learned in 3rd grade) to extend the usefulness of LUT multiplication.  Consider the long hand multiplication:

67   x 54 28 240 350 +3000 3618

67   x 54 28    240 350 +3000 3618

67   x 54 28    240 350 +3000 3618

67   x 54 28    240 350 +3000 3618

By performing the multiplication one digit at a time and then shifting and summing the individual partial products, the size of the memorized times table is greatly reduced.  While this example is decimal, the technique works for any radix.  The order in which the partial products are obtained or summed is not important.  The proper weighting by shifting must be maintained however.

The example below shows how this technique is applied in hardware to obtain a 6x6 multiplier using the 3x3 LUT multiplier shown above.  The LUT (which performs multiplication of a pair of octal digits) is duplicated so that all of the partial products are obtained simultaneously.  The partial products are then shifted as needed and summed together.  An adder tree is used to obtain the sum with minimum delay.

The LUT could be replaced by any other multiplier implementation, since LUT is being used as a multiplier.  This gives the insight into how to combine multipliers of an arbitrary size to obtain a larger multiplier.

The LUT multipliers shown have matched radices (both inputs are octal).   The partial products can also have mixed radices on the inputs provided care is taken to make sure the partial products are shifted properly before summing.  Where the partial products are obtained with small LUTs, the most efficient implementation occurs when LUT is square (ie the input radices are the same).  For 8 bit LUTs, such as might be found in an Altera 10K FPGA, this means the LUT radix is hexadecimal.   For 4 bit LUTs, found in many FPGA logic cells, the ideal radix is 2 bits (This is really the only option for a 4 LUT: a 1 bit input reduces the LUT to an AND gate, and since each LUT cell has 1 output, it can only use one bit on the other input).

A more compact but slower version is possible by computing the partial products sequentially using one LUT and accumulating the results in a scaling accumulator.  Note that in this case, the shifter would need a special control to obtain the proper shift on all the partials

Computed Partial Product Multipliers

	Partial product optimization for FPGAs having small LUTs
	Fewer partial products decrease depth of adder tree
	2 x n bit partial products generated by logic rather than LUT
	Smaller and faster than 4 LUT partial product multipliers

A  partial product multiplier constructed from the 4 LUTs found in many FPGAs is not very efficient because of the large number of partial products that need to be summed (and the large number of LUTs required).  A more efficient multiplier can be made by recognizing that a 2 bit input to a multiplier produces a product  0,1,2 or 3 times the other input.  All four of these products are easily generated in one step using just an adder and shifter.  A multiplexer controlled by the 2 bit multiplicand selects the appropriate product as shown below.  Unlike the LUT solution, there is no restriction on the width of the A input to the partial product.  This structure greatly reduces the number of partial products and the depth of the adder tree.   Since the 0,1,2 and 3x inputs to the multiplexers for all the partial products are the same, one adder can be shared by all the partial product generators.  This structure works well in coarser grained FPGAs like the Xilinx 4K series.

2 x n bit partial product generated with adder and multiplexer

The Xilinx Virtex device includes an extra gate in the carry chain logic that allows a 4 input LUT plus the carry chain to perform a 2xN partial product, thereby achieving twice the density otherwise attainable.  In this case, the adder (consisting of the XOR gates and muxes in the carry chain) adds a pair of 1xN partial products obtained with AND gates.  The extra AND gate in the carry logic allows you to put AND gates on both inputs of the adder while maintaining a 4 input function.

2 x n bit computed partial product implemented in Xilinx Virtex using special MULTAND gate in carry chain logic

Constant Coefficient Multipliers

	Multiplies input by a constant
	LUT contains custom times table
	Width of constants do not affect depth of adder tree
	All LUT inputs available for multiplicand
	More efficient than full multiplier
	Size is constant regardless of value of constant (assuming equal constant bit widths)

A full multiplier accepts the full range of inputs for each multiplicand.  If one of the multiplicands is a constant, then it is far more efficient to construct a times table that only has the column corresponding to the constant value.  These are known as constant (K) Coefficient Multipliers or KCM's. The example below multiplies a 5 bit input (values 0 to 31) by a constant 67.  Note that with a constant multiplier, all of the LUT inputs are available for the variable multiplicand.  This makes the KCM more efficient than a full multiplier (fewer partial products for a given width).

	5 bit input * 67
input	00	01	10	11
000	0	536	1072	1608
001	67	603	1139	1675
010	134	670	1206	1742
011	201	737	1273	1809
100	268	804	1340	1876
101	335	871	1407	1943
110	402	938	1474	2010
111	469	1005	1541	2077

When the LUT does not offer enough inputs to accommodate the desired variable width, several identical LUTs may be combined using the partial products techniques discussed above.  In this case, the constant multiplicand is full width, so the partial products will be m x n where m is the number of LUT inputs and n is the width of the constant.

Limited Set LUT Multipliers

	Multiplies input by one of a small set of constants
	Similar to KCM multiplier
	LUT input bit(s) select which constant to use
	Useful in modulators, other signal processing applications

In signal processing, there are often instances where one multiplicand is taken from of a small set of constant values.  In these cases, the KCM multiplier can be extended so that the LUT contains the times tables for each constant.  One or more of the LUT inputs select which constant is used, while the remaining inputs are for the variable multiplicand.  The example below is a 6 LUT containing times tables for the constants 67 and 85.  One bit of the input selects which times table is used. The remaining inputs are the 5 bit variable multiplicand (values from 0 to 31).  Again, the input width can be extended using the partial product techniques discussed previously.

	5 bit input * 67				5 bit input * 85
	000	001	010	011	100	101	110	111
000	0	536	1072	1608	0	680	1360	2040
001	67	603	1139	1675	85	765	1445	2125
010	134	670	1206	1742	170	850	1530	2210
011	201	737	1273	1809	255	935	1615	2295
100	268	804	1340	1876	340	1020	1700	2380
101	335	871	1407	1943	425	1105	1785	2465
110	402	938	1474	2010	510	1190	1870	2550
111	469	1005	1541	2077	595	1275	1955	2635

Constant Multipliers from Adders

	Adder for each '1' bit in constant
	Subtractor replaces strings of '1' bits using Booth recoding
	Efficiency, size depend on value of constant
	KCM multipliers are usually more efficient for arbitrary constant values

The shift-add multiply algorithm essentially produces m 1xn partial products and sums them together with appropriate shifting.  The partial products corresponding to '0' bits in the 1 bit input are zero, and therefore do not have to be included in the sum.   If the number of '1' bits in a constant coefficient multiplier is small, then a constant multiplier may be realized with wired shifts and a few adders as shown in the 'times 10' example below.

0      0000000 1     1011001 0    0000000  1  +1011001       1101111010

In cases where there are strings of '1' bits in the constant, adders can be eliminated by using Booth recoding methods with subtractors.  The 'times 14 example below illustrates this technique.  Note that 14 = 8+4+2 can be expressed as 14=16-2, which reduces the number of partial products.

0      0000000 1     1011001 1    1011001  1  +1011001       10011011110

0       0000000 -1   1110100111 0     0000000 0    0000000  1  +1011001        10011011110

Combinations of partial products can sometimes also be shifted and added in order to reduce the number of partials, although this may not necessarily reduce the depth of a tree.  For example, the 'times 1/3' approximation (85/256=0.332) below uses less adders than would be necessary if all the partial products were summed directly.   Note that the shifts are in the opposite direction to obtain the fractional partial products.

Clearly, the complexity of a constant multiplier constructed from adders is dependent upon the constant.  For an arbitrary constant, the KCM multiplier discussed above is a better choice.  For certain 'quick and dirty' scaling applications, this multiplier works nicely.

Wallace Trees

	Optimized column adder tree
	Combines all partial products into 2  vectors (carry and sum)
	Carry and sum outputs combined using a conventional adder
	Delay is log(n)
	Wallace tree multiplier uses Wallace tree to combine 1 x n partial products
	Irregular routing
	Not optimum in many FPGAs

A Wallace tree is an implementation of an adder tree designed for minimum propagation delay.  Rather than completely adding the partial products in pairs like the ripple adder tree does, the Wallace tree sums up all the bits of the same weights in a merged tree.  Usually full adders are used, so that 3 equally weighted bits are combined to produce two bits: one (the carry) with weight of n+1 and the other (the sum) with weight n.  Each layer of the tree therefore  reduces the number of vectors by a factor of 3:2 (Another popular scheme obtains a 4:2 reduction using a different adder style that adds little delay in an ASIC implementation).  The tree has as many layers as is necessary to reduce the number of vectors to two (a carry and a sum).  A conventional adder is used to combine these to obtain the final product.  The structure of the tree is shown below. The red numbers after each full adder in the illustration indicate the bit weights of each signal.  For a multiplier, this tree is pruned because the input partial products are shifted by varying amounts.

A section of an 8 input wallace tree. The wallace tree combines the 8 partial product inputs to two output vectors corresponding to a sum and a carry.  A conventional adder is used to combine these outputs to obtain the complete product..

If you trace the bits in the tree (the tree in the illustration is color coded to help in this regard), you will find that the Wallace tree is a tree of carry-save adders arranged as shown to the left.  A carry save adder consists of full adders like the more familiar ripple adders, but the carry output from each bit is brought out to form second result vector rather being than wired to the next most significant bit.  The carry vector is 'saved' to be combined with the sum later, hence the carry-save moniker.

A Wallace tree multiplier is one that uses a Wallace tree to combine the partial products from a field of 1x n multipliers (made of AND gates).  It turns out that the number of Carry Save Adders in a Wallace tree multiplier is exactly the same as used in the carry save version of the array multiplier.  The Wallace tree rearranges the wiring however, so that the partial product bits with the longest delays are wired closer to the root of the tree.  This changes the delay characteristic from o(n+n) to o(n+log(n)) at no gate cost. Unfortunately the nice regular routing of the array multiplier is also replaced with a rats-nest.

A Wallace tree by itself offers no performance advantage over a ripple adder tree

To the casual observer, it may appear the propagation delay though a ripple adder tree is the carry propagation multiplied by the number of levels or o(n*log(n)).  In fact, the ripple adder tree delay is really only o(n + log(n)) because the delays through the adder's carry chains overlap.  This becomes obvious if you consider that the value of a bit can only affect bits of the same or higher significance further down the tree.   The worst case delay is then from the LSB input to the MSB output (and disregarding routing delays is the same no matter which path is taken).  The depth of the ripple tree is log(n), which is the about same as the depth of the Wallace tree. This means is that the ripple carry adder tree's delay characteristic is similar to that of a Wallace tree followed by a ripple adder!  If an adder with a faster carry tree scheme is used to sum the Wallace tree outputs, the result is faster than a ripple adder tree.  The fast carry tree schemes use more gates than the equivalent ripple carry structure, so the Wallace tree normally winds up being faster than a ripple adder tree, and less logic than an adder tree constructed of fast carry tree adders.  An ASIC implementation may also benefit from some 'go faster' tricks in carry save adders, so a Wallace tree combined with a fast adder can offer a significant advantage there.

A Wallace tree is often slower than a ripple adder tree in an FPGA

Many FPGAs have a highly optimized ripple carry chain connection.  Regular logic connections are several times slower than the optimized carry chain, making it nearly impossible to improve on the performance of the ripple carry adders for reasonable data widths (at least 16 bits).  Even in FPGAs without optimized carry chains, the delays caused by the complex routing can overshadow any gains attributed to the Wallace tree structure.  For this reason, Wallace trees do not provide any advantage over ripple adder trees in many FPGAs. In fact due to the irregular routing, they may actually be slower and are certainly more difficult to route.

Booth Recoding

Booth recoding is a method of reducing the number of partial products to be summed.   Booth observed that when strings of '1' bits occur in the multiplicand the number of partial products can be reduced by using subtraction.  For example the multiplication of 89 by 15 shown below has four 1xn partial products that must be summed.   This is equivalent to the subtraction shown in the right panel.

1       1011001        1      1011001 1     1011001 1    1011001  0  +0000000          10100110111

1      -1011001 1      0000000 1     0000000 1    0000000  0  +1011001          10100110111
